S100 Car Smoke Leak Detector EVAP Vacuum Leakage Locator ANCEL DC12V Car Diagnostic Tool Automotive Oil Pipe Smoke Generator

ANCEL S100 DC12V Fuel Pipe Leak Locator Auto Smoke Leak TesterCar Smoke Leak Detector EVAP Vacuum Leakage Diagnostic Tool

Ancel S100 Car Smoke Leak Detector is a professional auto pipe leak detect tool. It will help us position cars motorcycles leakage on pipe system quickly and exactly.

Why Choose ANCEL S100?

1.Wide Range Of Applications

For detecting the leakage of pipe systems on cars, motorcycles, snowmobiles, off-road vehicles, ATVs, light trucks and speedboats boats.Works on all car makes and models.

2.Find All Types Of Leaks:

The S100 smoke leak detector can do the following work - EVAP systems test, vacuum leaks, low pressure turbo leaks, intake manifolds, cooling exhaust systems, door & windows seals, EGR system test, various pipe fittings test, oil leaks, and more!

3.Powerful Smoke:

Equipped with ANCEL's latest smoke generator and 1/2PSI high pressure unit, which ensures continuous output of a large amount of smoke. The dense smoke output detects even the smallest leaks and helps you diagnose faults quickly and accurately. Significantly improves the efficiency of diagnosis.

4.High- Quality Performance:

High temperatures are generated during the operation of the smoking machine, which will cause the internal parts to permanently disintegrate at high temperatures and the machine will stop working. Therefore, the S100 smoke machine uses a solid, thick metal structure to protect the internal parts from heat, which greatly extends the service life.

5.Small Size :

Most smoking machines are relatively large, which is a hindrance when transporting and storing them. This machine weighs only 3 pounds, is small and lightweight, making it not only easy to store, but also easy to transport. It is an indispensable tool for any car owner.

Why Do You Need A S100 Smoke Machine?

Unmetered air entering an engine will cause all sorts of lean conditions. You cannot see the leaks without the help of smoke. A vacuum line can just become porous over time but look ok. O-rings can become hardened and no longer seal. Plastic parts can be separated or cracked.

Exhaust leaks can be bad for your health and can cause backfiring in carbureted cars. You can use the S100 smoke machine to help find exhaust leaks, without running the engine and gassing yourself.

You can smoke test EVAP systems, vacuum leaks, low-pressure turbo leaks, intake manifolds, cooling / EGR / exhaust systems, worn rubber, gaskets, seals, connectors, and more.

In modern cars, many check engine codes are set off by an air/vacuum leak. Quickly dialing in the problem will save you time and money in a shop and help a home mechanic find the problem instead of just changing parts.

Full System Diagnostics, Don't Miss Any Leaks.

▶Crankcase System Test: excessive pressure or corrosion of the crankcase is the main reason to damage the seal of the crankcase and cause oil leakage.

▶Intake System Test: leakage in the air intake system will lead to insufficient intake of the car engine, which will result in scant engine power.

▶Car Sealing Test: poor airtightness of the car may lead to a lot of inconvenience like inability to keep warm dusty, not soundproof, and not waterproof , etc.

▶Fuel Tank System Test: possible reasons for the leakage of the fuel tank system: 1. There are gaps in the fuel tank and pipeline caused by improper installation. 2. The fuel tank cover is not sealed enough

▶Turbo Test: the leakage of coolant would cause the engine to report high water temperature.

▶Various Pipe Fittings Test: automobile pipes can be classified according to their functions: brake hoses, power steering hoses, cooling system hoses, air conditioning system hoses, turbocharger hoses, fuel hoses, intake and exhaust system hoses.

▶EVAP System Test: Leakage of the fuel evaporation system will cause fuel vapor to leak into the atmosphere, causing waste and pollution or unstable engine idling

▶Exhaust System Test: Uncleaned harmful gases to be discharged into the atmosphere or increase vehicle noise is the main disadvantage when leaks happened in the exhaust.

6.Safe To Use:

By constantly changing materials and improving heating technology, the smoke produced by S100 smoke machine is environmentally friendly and harmless. When the operating temperature of the machine exceeds 75°C, it will shut down automatically. This effectively ensures the safety of each car owner.

Wide Range Of Applications

For detecting the leakage of pipe systems on cars,motorcycles,snowmobiles,off-road vehicles, ATVS,light trucks and speedboats,Suitable for all car models

Overheat & Anti-Frost Protection

For detecting the leakage of pipe systems on cars,motorcycles,snowmobiles,off-road vehicles, ATVS,light trucks and speedboats,Suitable for all car models.

Overheat Protection
When the temperature of the device exceeds 75℃, power protection will be intelligently activated to turn it off.

Anti-frost Protection
The device can also work normally at -20℃.

Powerful And Easy To Operate

The ANCEL S100 has its own air pump,so it does not have to rely on other air machines. Connect the detector with DC12V battery , it can output lots of smoke within 30 seconds after on.

Notice: Maintenance technicians need a certain knowledge base of engine structure.

How To Do Leakage Test?

Step 1: Turn off the power to the car, remove the air filter and throttle connector. Note: If you need to test the EVAP system, you need to manually close the solenoid valve

Step 2: Pour baby oil between the max and min oil volume line, connect the power cord to the 12V car battery, choose the appropriate adapter cone to connect the smoke nozzle and the system.

Step 3: Press the air control switch, wait for 30 seconds, and listen for the squeaking sound to check whether there is a leak in the pipeline or not.

Step 4: Press the smoke control switch, when evident smoke is appearing from the smoke nozzle, reinsert the smoke nozzle into the adapter cone, visible smoke can help you pinpoint the location of the leak.

Caution：

1.When you use this ANCEL S100 Car Smoke Leak Detector for the first time, fill with 20ml oil . Please be careful NOT to beyond this range.

2.The testing liquid : both liquid paraffin and baby oil are OK.

3.Fresh oil can be filled with only when the smoke gets thin, and it can’t be filled over 20ml each time.

4.Before filling fresh oil, please pour out the left oil in the detector & replace the detector oil regularly.

5.During the process of leak detection, please keep away from smoke-sensitive parts.

6.Do NOT run the detector over 8 minutes continuously. It needs interval rest.

7.The detector has an intelligent protector, if it exceeds the working limit, such as over 75 ℃, it will automatically turn off the power. In this case, please operate it later.

8.The round part of this detector has temperature, please be careful to avoid burns.

9.If the test pipe needs to be disconnected in the middle, please secure the other side with a rubber stopple.

Smoke Leak Detector ANCEL S100

Output pressure:0.5PSI
Output Volume:<8LPM
Power Supply:DC12V
Current:5AMP

Product Package:

1pc * ANCEL S100 Car Smoke Leak Detector Main Unit
1pc * Power Cord
1pc * Hook up
2pc * EVAP Kit
1pc * Smoke Delivery Hose
1pc *Air Adapter
