GT30 GT3076 GT3076R Universal Turbo for all 6 / 8 cyl 3.0L-5.0L engine Turbocharger 500HP

The GT3037 Turbocharger is a large turbo capable of generating 500 HP, depending on application and with the correct tuning. The GT3037 is generally used for larger displacement engines of 3.0L and up, since these types of engines can produce enough exhaust volume to push the GT3037.

Application

Perfect for all 6 / 8 cyl 3.0L-5.0L engine

Horse Power:

Capable of Boosting Horse Power up to 500HP

Cooling Type:

Water + Oil Cooled

Specification

Horse Power: Capable of Boosting Horse Power up to 500BHP

Cooling Type: Water + Oil

Exhaust Inlet (Turbo Manifold) Flange: Standard T3 Flange

Exhaust Outlet (Downpipe) Flange: Standard 4-Bolt

Turbine Trim: 74.2

Turbine Inducer Diameter:64.8

Turbine Exducer Diameter: 55.8

Turbine A/R: 0.82

Compressor Trim: 48.1

Compressor Inducer Diameter: 52.7

Compressor Exducer Diameter: 76

Compressor A/R:0.6

Bearing: Journal Bearing

Warranty: 2 Year

Internal Wastegate: No

Notice

* Please check the specifications carefully before buying. If you are not sure about these information, please feel free to contact us.

* This is universal application turbo, so modification might be required for some vehicles.

* Professional installation is highly recommended(No Instruction Included)

1. Due to the light and screen difference, the item's color may be slightly different from the pictures.

2. Please allow 0.5-2 cm differences due to manual measurement.

We highly recommend you make sure the points below before installing:
