Gate Remote Control For ATA PTX5 PTX-5v1 PTX-5 GDO Rolling Code Command 433MHZ Wireless Handheld Garage Door Opener Transmitter

For ATA PTX5 Garage Door Remote Conrol Replacement ATA PTX5V2 PTX5V1 PTX2 PTX2V1 PTX2V2 Tricode GDO Hand Transmitter

Specifications

1. Model：RMTPTX5
2. Type of programming：Programming with the receiver
3. Frequency：433.92MHz
4. Code：Rolling Code
5. Buttons：4
6. Woring Range：30m-100m (open space)
7. Battery：Include Battery
Security of use：dynamic code provides a high level of security, non-copyable code.

Compatible model

---Roller Door Motors

GDO6v3 EasyRoller
GDO6v4 EasyRoller
GDO8v3 Shedmaster
GDO10v1 Toro
GDO10v2 Toro
GDO10v3 Toro
GDO12 Hiro
And all other compatible TrioCode receivers and motors

---Sectional Door Motors

DCB-05 (Dual Gate Controller)
GDO7v2(SecuraLift)
GDO7v3(SecuraLift)
GDO9v2(SecuraLift)
GDO-9v3 (Dynamo)
GDO9v3(Dominator)
GDO-10v1 (Toro)
GDO11v1(Ero)
Tempo ATS-2
And all other compatible TrioCode receivers and motor

---Gate Motors
SGO-1 (Elite)
SGO1v3 Elite
SGO1v4 Elite
NES24v1 NeoSlider
NES24v2 NeoSlider
NES24v3 NeoSlider
NES500 Neoslider
NES800 NeoSlider
And all other compatible TrioCode receivers and motor

---Industrial Openers

Axess Pro Series 3100 (Logic Console Only)
Axess Pro Series 3300 (Logic Console Only)
Axess Pro 1505 Overhead
Axess Pro 600 Slider
Axess Pro 800 Slider
Axess Pro 200 Swing
Axess Pro 400 Swing

---Receivers

FHCRX1 Single Channel Receiver
FHCRX1v2 Single Channel Receiver
FHCRX2 Dual Channel Receiver
FHCRX2v2 Dual Channel Receiver
FHRX2 Plug-In Board Receiver

Access to receiver required. Please make sure you got access to your receiver/opener before purchase.

Disclaimer: Your remote control must be the same as the picture and your model must be in the list, we will not be responsible for wrong purchase

Include:

1 X Remote Control
1 X Battery
1 X Keychain
1 X English Manual

Note：does not suit the PTX4 remote controls as they are an older series of remote control

How to program ?

1. Press and hold the (DOOR-CODE) learn button.
2. Press and hold one of the four buttons on the remote control (hold for 2 seconds), then release the remote control button (2 seconds), then press the same button again (2 seconds). The (DOOR-CODE) learning button must be pressed all the time during the operation.
3. Release the learn button and remote control button.
4. Press the remote control button to test.
