Waveshare ESP32-S3 7.0 inch 1024x600 LCD Development Board ESP32 Display Touchscreen LVGL GUI for Arduino IDE ESP-IDF PlatformIO

Wiki:

FAQ

Answer:

If there's no screen response after programming the code, check whether the correct configurations are set in Arduino IDE -> Tools, select the corresponding Flash (16MB) and enable PSRAM (8MB OPI))

Answer:

The path to install the library contains Chinese characters, resulting in the inability to find the library file

Answer:

Please install the Arduino ESP32 that we provided to solve this issue

Answer:

Yes, you can also customize the frequency of consecutive frames. When the frequency is too high and the computer freezes, it may cause bus errors

Answer:

You can set the board to download mode to solve this issue. Power off completely, press and hold the Boot button and power it on again, then release it, enter the download mode, re-flash the program, reset and run.

Please try to press the fullclean button in the status bar and recompile the flashing, this function is to clean up all the compiled content by clicking when the project compilation error or other operations pollute the compiled content

Answer:

Some AppData folders are hidden by default and can be set to show

English system: Explorer->View->Check "Hidden items"

Chinese system: File Explorer -> View -> Display -> Check "Hidden Items"

Answer:

Press the Windows + R keys to open the "Run" dialog box, input devmgmt.msc and press Enter to open the Device Manager; Expand the "Port (COM and LPT)" section, here it will list all the COM ports and their current status.

Answer:

It's normal for the first compilation to be slow, just be patient

Answer:

If there is a reset button on the development board, press the reset button; if there is no reset button, please power it on again

Answer:

Install

 and flash again.

Answer:

Please refer to

Answer:

The LCD screen display chip used in this product is ST7701, and the touch chip is GT911, we recommend that you directly refer to the demos of Arduino or ESP-IDF

Answer:

Click this link to view the solution:

Answer:

In the main function, comment out the code shown in the red box.
