Creality CR Touch Kit Auto Leveling Upgrade 32 Bit Sensor for Ender 3 V2/3 Pro/Ender 5/CR-10/ Ender-3 SE/KE Without Bracket

Please note: We have two options: Set 1 (without stand) .

Please check carefully before placing your order. Thank you.

CR Touch Auto Leveling Kit (set 2)

Compatible Models：

Ender-3_Ender-3 V2_Ender-3Pro_Ender-3s_Ender-3 Max_Ender-5_Ender-5S_Ender-5 Pro_CR-10

CR Touch Auto Leveling Standard Kit without Bracket (set 1)

Compatible Models：

Ender-3 NEO/Ender-3 V2 Neo/Ender-3 Max Neo/Ender-3 S1 Plus/Ender-3 S1/Ender-3 S1 Pro/CR-10 Smart Pro/Ender-3 V3 SE/Ender-3 V3 KE

Also suitable with the after-sales repair replacement of CR touch

CR Touch

CR Touch Auto Leveling Standard Kit

Multi-point detection Smart compensation

High precision Low power con-sumption

Easy to install Strong compatibility

Independent researchand development Stable function

Product Description

1. Product name: CR Touch

2. Work rate: ＜1W

3. Product size: 27*17.5*39.3mm

4. Packing size: 100*100*35mm

5. Rated voltage: 5V

6. Accuracy: Positioning accuracy ≤0.04

7. Probe route: 6mm

8. Product weight: 11.5g+/-2g

9. Operating temperature: ≤65℃

10. Service life: About 100,000 probe detection times

11. G.W.: 100g

12. N.W.: 50g.

Product Features

1. Multi-point detection Smart compensation: The system builds a virtual plane based on the height of each point and calculates the title angle between the nozzle and the platform to automatically compensates for different points.

2. Independent research and development Stable function: Compare with the traditional automatic leveling, it is compatible with more 3D printer platforms, more stable and cost-effective.

3. More durable mental probes: CR Touch is upgraded to a metal probe, which reduce wear and tear and greatly prolong its service life.

4. High-precision electromagnetic components+Photoelectric sensor: After the electromagnetic component is powered on, the probe is extended under suction. When the probe touches the printing platform, the photoelectric

5. sensor on the PCB board detects the contact signal, and the system records the current height of the platform.

6. Wide application strong compatibility: Compatible with PEI/Stickers/Glass/Metal and more printing platform materials.

7. Easy to install and easy to use: Download the CR Touch program from the Creality 3D official website and copy it to the TF/SD card. Insert it directly into the card slot of the 3D printer. The program can be updated after power on.

Widely compatible with a variety of printers

Compatible with most FDM 3D printers and most auto leveling products

Multi-point detection Smart compensation

CR Touch performs multi-point detection on theprinting platform and records the heigh of each detection point. The system builds a virtual plane based on the height of each point and calculates the tilt angle between the nozzle and the platform to automatically compensates for different points.

100000 times

Stable quality and long service life. It can be reused for more than 100,000 times.

Independent research and development Stable function

CR Touch is a Creality self-developed 3D printer platform leveling solution based on hundreds of millions of user data used by the creators.Compared with the traditional automatic leveling,it is compati-ble with more 3D printer platforms,more stable and cost-effective.

More durable metal probes

CR Touch is upgraded to a metal probe, which reduce wearand tear and greatly prolong its service life.

High-precision electromagnetic components + Photoelectric sensor

After the electromagnetic component is powered on,the probe is extended under suction. When the probe touchesthe printing platform, the photoelectric sensor on the PCB boarddetects the contact signal, and the system records thecurrent height of the platform.

Wide application strong compatibility
