Topton Mini PC Gamer Intel Ultra 9 285H ES 7 255H ES 5 235H ES OCuLink USB4 2x2.5G LAN 2xNVMe Desktop Computer Windows 11 WiFi6E

Notice:

This link is for ES(engineering sample) CPU, ES CPU about 5-10% lower in performance and frequency compared to the official version. Do Not display the CPU model on the computer, but instead display as Genuine Intel(R) 0000. The corresponding CPU version ID can be found on the Intel official website.

Model name: D12 Pro

Material: Metal body

Dimension: palm size, 132mm(L)x132mm(W)x50.5mm(H)

CPU:

1. Genuine Intel(R) 0000 16-cores 16-threads, 24M L3 cache(Ultra 9-285H ES Version)

2. Genuine Intel(R) 0000 16-cores 16-threads, 24M L3 cache(Ultra 7-255H ES Version)

3. Genuine Intel(R) 0000 14-cores 14-threads, 18M L3 cache(Ultra 5-235H ES Version)

4. Genuine Intel(R) 0000 16-cores 22-threads, 24M L3 cache(Ultra 9-185H ES Version)

GPU: Intel Arc Graphics

Ram: 2 x SO-DIMM DDR5 slots, max up to 128GB 4800MHz

SSD: Support 2xM.2 2280 NVME/PCIE4.0x4 (compatible with PCIE3.0)

WiFi: 802.11 AX WiFi6E with Bluethooth5.3

RJ45: 2 x 2.5G Intel i226-V

Front I/O: 2 x USB 3.2, 1 x OCuLink(PCIE Gen4x4), 1 x Type-C USB4.0(40Gbps), 1 x Audio, 1 x Switch

Rear I/O: 1 x USB 3.2, 1 x USB 2.0, 1 x HDMI2.1, 1 x DP2.1, 2 x 2.5G RJ45 LAN, 1 x DC-IN

OS: Activated Windows 11 Pro pre-installed(except no ram no storage bundle)

Power adapter plug: EU/US/UK/AU plug based on buyer's country
