Speedbox Bosch - Speed Limiter Tuning Chip for Electric Bicycles with Bosch Motors

Third-Generation Smart Product That Allows You to Adjust the Speed Limit of Your Electric Bicycle.

The Speedbox 3.0 Allows for Arbitrary Configuration of Electric Speed Limiters.After Installing the Tuning, You Can Check the Actual Values Such as the Maximum Speed, Average Speed, Daily Mileage, and Range.

How Does Speedbox 3.0 Work?

You Can Activate the Speedbox 3.0 on the Electric Bike Display. after a Short Activation of the Walk Function, the Display Will Briefly Show 9.9 Km/H (6.2 Mph) and from That Point Onwards You Can Ride at an Unlimited Speed.

To Disable the Tuning Function, Reactivate the Walk Function.The Display Shows 2.5 Km/H (1.6 Mph) and the 25 Km/H Speed Limit Will Be Reactivated.The Electric Bicycle Functions as It Did before the Tuning Was Installed.

We Are Also Prepared for Electric Bicycles That Do Not Have a Classic Control Panel with the Walk Function.In This Case, Simply Use the Button Combination - + - + and Speedbox Will Be Activated.It Can Also Be Deactivated in the Same Way.

To Set the Maximum Speed, You Can Switch between the Following Modes: Turbo - Emtb - Tour - Eco - Tour - Emtb - Turbo.Then the Current Speed Limit Will Be Displayed.To Change the Maximum Speed, Briefly Press the Walk Function or Rotate the Wheel 360 Degrees.°.Screen Displays 1.5 Km/H, Which Corresponds to the Limit of 15 Km/H, 2.0 Corresponds to the Limit of 20 Km/H, 2.5 Corresponds to 25 Km/H, 3.0 Corresponds to 30 Km/H, 9.9 Corresponds to 99 Km/H, Etc.The Last Displayed Limit Is Saved after Five Seconds of Inactivity.

When the Speedbox 3 Is Used.0 with the 4Th Generation Bosch Motors (2020 and Later), the Electric Bicycle Needs to Be Turned on after the End of the Ride Until the Display Shows a Constant 0.0 Km/H.During This Phase, the Screen Will Display the Remaining Time (in Minutes).Then You Can Safely Turn Off the Bike and Look Forward to the Next Ride.

To Connect the Speedbox to an Electric Bicycle, We Use Colored Connectors Equipped with a Wrench for a Proper Connection, Making the Product Really Easy to Install.You Can Download the Instructions or Watch Videos That Will Guide You to Install Speedbox.Removing the Product Is as Easy as Assembling It.If You Have Any Connection Issues, Do Not Hesitate to Contact Us.

If You Want a Speedbox on a New Bike, You First Need to Ride at Least 10 Kilometers on the Bike.

Notice

It Must Be Taken into Account That the Use of Modified Electric Bicycles in Infrastructures May Conflict with Current Legislation in Some Countries.The Manufacturer Is Not Responsible for Any Damage Resulting from the Use of Speedbox Products.Electric Bicycles Equipped with Speedbox Products Cannot Be Used on Roads, Bike Paths, and Public Areas.Electric Bicycles Equipped with Speedbox Products Can Only Be Used on Your Own Property, at Your Own Risk.The Use of Speedbox Products Can Void the Warranty on Your Electric Bicycle.

We Recommend the Use of Additional Protective Products to Prevent Injuries.

In Short Breaks, to Continue Driving Smoothly, We Recommend Keeping One Foot on the Pedal so That the Countdown Doesn'T Start.

In Case of a Longer Pause, You Should Allow Yourself at Least One Partial Countdown.

Do Not Turn Off the Screen Until the Countdown Is Complete.

We Do Not Recommend Upgrading the Software.

Please Note That the Speedbox Product Warranty Does Not Cover Poor Product Performance Caused by a Motor Upgrade.
