CONTEC Veterinary Color Doppler Ultrasound Machine Convex & Linear Probe for Animals Pet with WiFi and Software

CONTEC Veterinary Color Doppler Ultrasound Machine Handheld Convex & Linear Probe for Animals Pet with WiFi and Software for Horse Sheep Dog Cat Pig

                 Diagnostic in Farm Clinic Home

CMS1600A VET （CMS1600A VET Colour Doppler 80E 3 in 1）

Introduction

CMS1600A-VET is a handheld dual-probe color Doppler ultrasound diagnostic system composed of a

host and a particular control software. It adopts ultrasonic Doppler technology and ultrasonic echo

theory to collect blood flow movement, tissue movement information and organ tissue imaging. Small

in volume, easy to operate, which is used for clinical ultrasound examination of canine,feline, ovine, bovine,equine, etc. The internal professional measurement software package can fully meet the clinic diagnostic requirement.

Function

1)Charging mode: wireless, wired (Type-C).

2)The effective transmission distance of WiFi connection (between the main unit and the particular

control software) is not less than 10 m (in an open area).

3)Support full-screen display.

4)Image flip function.

5)8-segment TGC adjustment.

6)Many parameters are adjustable.

7)With patient management system.

8)Cine-loop function

9)Storage function of DICOM file

10)Working mode: B, B/M, C, PW

11)With the measurement functions and software package that can meet the requirements of clinical diagnosis.

Performance

Maximum scanning depth: 305 mm

Cine-loop storage: 1000 frame

Measurement items: length, circumference, area, depth, heart rate, duration, distance, speed, S/D

ratio, obstetric measurement package.

Safety

Type of protection against electric shock: internally powered equipment

Degree of protection against electric shock: type BF applied part

Accessories

Particular APP

One User Manual

One wireless charging base

One quick charger

One data line

Physical characteristic

Dimension: 124 mm (L) × 54 mm (W) × 24 mm (H)

Weight: less than 1 kg

CMS1600B VET Veterinary Colour Dopple 128E 3 in 1

Introduction

CMS1600B-VET is a handheld dual-probe color Doppler ultrasound diagnostic system composed of a host and a particular control software. It adopts ultrasonic Doppler technology and ultrasonic echo theory to collect blood flow movement, tissue movement information and organ tissue imaging. Small in volume, easy to operate, which is used for clinical ultrasound examination of canine, feline, ovine, bovine,equine, etc. The internal professional measurement software package can fully meet the clinic diagnostic requirement.

Function

1)Charging mode: wireless.

2)The effective transmission distance of WiFi connection (between the main unit and the particular control software) is not less than 10 m (in an open area).

3)Support full-screen display.

4)Image flip function.

5)8-segment TGC adjustment.

6)Many parameters are adjustable.

7)Cine-loop function

8)Storage function of DICOM file

9)Working mode: B, 2B, B/M, C, PW

10)With the measurement functions and software package that can meet the requirements of clinical diagnosis.

Performance

Maximum scanning depth: 305 mm

Cine-loop storage: 1000 frame

Measurement items: length, circumference, area, depth, heart rate, duration, distance, speed, S/D ratio, obstetric measurement package.

Safety

Type of protection against electric shock: internally powered equipment

Degree of protection against electric shock: type BF applied part

Accessories

Particular APP

One User Manual

One wireless charging base

One quick charger

One data line

Physical characteristic

Dimension: 161 mm (L) × 73 mm (W) × 30 mm (H)

Weight: less than 1 kg

Optional bag
