New Version CNC Solder Paste Stencil Fixture - Mini Steel Stencil Printing Jig for PCB Assembly (Supports Double-Sided SMT)

New Version CNC Solder Paste Stencil Fixture - Mini Steel Stencil Printing Jig for PCB Assembly (Supports Double-Sided SMT)

Specifications:

Name: CNC Solder Paste Stencil Fixture (New Version)

Material: High-strength CNC aluminum alloy

PCB Size Support: Max 10cm × 13cm

PCB Thickness: 0.8mm / 1.0mm / 1.2mm / 1.6mm

Stencil Fixation: Screw-fastened

Hinge Mechanism: Upgraded resistance hinges for effortless open/close

Alignment Aid: Laser-etched millimeter scales

Compatibility: Steel stencils, FR4/Phenolic PCB substrates

Weight: 550g (Compact & portable)

Applications: SMT soldering, DIY PCB assembly, rework stations

Features:

1.Upgraded CNC Aluminum Design: Precision-machined with surface oxidation for durability and anti-corrosion.

2.Enhanced Stability: Thickened clamps to secure stencils (0.8–1.6mm PCBs) and prevent shifting during printing.

3.Double-Sided SMT Support: Holds PCBs up to 10×13cm for versatile prototyping or small-batch production.

4.User-Centric Upgrades: Upgraded resistance hinges for smooth operation + laser-etched scales for precise alignment.

New Version Enhancements:

Reinforced Clamp Thickness: Securely holds double-sided PCBs without warping.

Smoother Hinges: Reduced effort to open/close, ideal for high-frequency use.

Precision Scales: Laser markings enable quick PCB/stencil alignment.

Why Upgrade to This Fixture?

Lab-Grade Accuracy: ±0.05mm stencil-to-PCB registration for flawless solder paste deposition.

No-Slip Design: Combined screw suits high-viscosity pastes.

Time-Saving: Scales and ergonomic hinges cut setup time by 50%.

Durability: Oxidation-treated surface resists scratches and flux residue.

Ideal For:

Electronics manufacturers requiring repeatable SMT printing.

Hobbyists building custom PCBs

Repair shops reballing BGA chips or replacing components.
