MCP2515 CAN BUS Shield Controller Board ELE Can Bus Shield for Arduino Mega Leonardo

CAN-BUS is a common industrial bus because of its long travel distance, medium communication speed and high reliability. It is widely used as the automotive diagnostic bus, and also commonly used on modern machine tools. This

CAN-Bus shield gives the Arduino CAN-Bus capability, It uses the Microchip MCP2515 CAN controller with MCP2551 CAN transceiver, the CAN connection is via a standard 9-way sub-D for use with OBD-II cable, ideal for automotive CAN application. The shield also has a Micro SD card holder, which helps you store the diagnostic information in the SD card directly, making this shield ideal for data logging application.

Features

Arduino Mega and Leonardo compatible

Implements CAN V2.0B at up to 1 Mb/s

SPI Interface up to 10 MHz

Standard (11 bit) and extended (29 bit) data and remote frames

Two receive buffers with prioritized message storage

Industrial standard 9 pin sub-D connector

Two LED indicators

SD card holder for information storage
