iFlight BLITZ M10 V2 GPS built-in compass 10th generation chip Small size, fast positioning, stable connection, model aircraft

Changelog

January 16, 2026: The 20*21*8 (Mini Version) Single-hole TPU mount has been changed to a universal Mini M10 GPS mount injection molded part.

Compatibility

20*21*8(Mini Version) compatibility:

Single-hole TPU mount:

Chimera7 Pro v2

iH3 O3

Nazgul Evoque F4/F5/F6

XL10 v6

BOB57 HD

Nazgul XL5/DC5 ECO V1.1

SH CineFlow 5

SH CineLR 7

Dual hole TPU mount:

Nazgul5 V3

Nazgul XL5/DC5 ECO V1

Taurus X8 Pro/V3

ProTek60 Pro

GPS TPU mount is not required:

Helion 10

25*25*6 Version compatibility:

Centurion X8 Frame Kit

Taurus X8 Pro Max

Description

The newly upgraded BLITZ M10 GPS V2 has arrived, offering faster and more stable satellite search. This advancement in technology provides users with a more reliable and efficient GPS experience.

Features

UBLOX M10 chip, low power consumption, strong signal

Compass module QMC5883L integrated

Built-in farad capacitor for faster hot start

High-precision positioning

Onboard LNA (Low Noise Amplifier), RF filter, and TCXO (temperature-compensated crystal oscillator)

10 Hz Refresh rate

Built-in Flash

Specificaitons

Compass module: QMC5883L

Baud Rate: 9600-460800 / 4800bps-921600bps (Default - 115200bps)

Sensitivity: Tracking: -167dBm

Cold start: 27s

Hot start: 1s

Maximum height: 80000m

Maximum speed: 500 m/s

Speed accuracy: 0.05 m/s

Maximum acceleration: 4G

Refresh Rate: 10 Hz

GPS patch antenna size: 18.2 x 18.2 x 4 mm / 25 x 25 x 6 mm

Total dimensions: 20 x 21 x 8 mm / 25 x 25 x 11 mm

Weight: 8g / 16 g

Input Voltage: 3.3-5.5 V

GPS pin definition: RX/TX UART

Compass pin definition: SDA/SLA

GNSS: GPS+SBAS+Galileo+QZSS+Glonass

Packing List

1 x BLITZ M10 GPS V2

1 x Cable set
