Autel MaxiPRO MP900TS TPMS Car Diagnostic Tools MP900-TS Automotive OBD2 Scanner CANFD&DoIP ECU Coding Upgraded of MS906TS MP900

Autel MaxiPRO MP900TS Scanner, 8-inch MP900-TS upgraded of MS906 PRO MS906TS MP900BT MP900, Top TPMS as MS906 Pro-TS, advanced ECU Coding, Bidirectional Scan Tool, 40+ Service, All System diagnostic, CAN FD&DOIP

Outstanding Performance, More User-friendly Experience

● 8-inch touchscreen with 1280*800 high resolution, smooth interaction
● Android 11.0 operating system, better experience
● 4G+64G high-capacity storage for faster speed
● 8M rear camera, clear and detailed

21+ Languages Support & 1 Year Free Update:

■ 1 Year Warranty and 1 Year Free Update.
■ Support Languages: English, Traditional Chinese, Spanish, French, German, Russian, Japanese, Korean, Polish, Portuguese, Swedish, Persian, Turkish, Thai, Vietnamese, Hebrew, Arabic, Indonesian English, Italian, Dutch.

( Please tell us about your S/N of machine to activate the language you need after you get it. Thanks~)

Why Choose Autel MP900TS?

● One Year Free Update Online
● 8-inch LCD Touch Screen with 1280*800 Display Quality, Android 11, 7700 mAh Battery Capacity.
● Newly Added Functions: Pre & Post Scan, Scan VIN & Scan License.
● Support Both Full System Diagnosis and Complete TPMS Functions.
● Bi-directional Control/Active Test
● 40+ service and maintenance tasks
● Support CAN FD/DoIP Protocols: Access New Communication Protocols of CANFD (Cover MY2020+ GM Models), and DOIP (Compatible with BMW E/F/G Chassis, Jaguar, LandRover Vehicle Makes).
● Battery Diagnose: Work with Autel BT506 to perform complete battery detection functions, including battery reset, battery registration, in-vehicle and in-vehicle testing, etc.
● Compatible with MaxiVideo MV108S: you can clearly understand the internal structure of the car, and present it on the tablet in pictures or videos.

Complete TPMS Functions:

Gathered all advantageous TPMS solutions of TS508, TS601, TS608, MP808-TS, MK808-TS, MS906-TS, and MS906 PRO-TS, Autel MaxiPRO MP900-TS automotive scanner diagnostic tool offers more checks & precise diagnostic results with one-stop process, no need to prepare extra TPMS tools with unneeded repair cost.

✅ Performing complete & accurate diagnostics for TPMS system;
✅ Providing sensor activation for OEM & Common Tire Sensor;
✅ Ading all TPMS sensor data & Checking sensor status;
✅ Pogramming IDs for Autel MX-Sensors within 60 seconds;
✅ Relearning 99% of TPMS sensors with vehicles’ ECU;
✅ Retrofitting & Modifying new TPMS module for older vehicles; and More.

Advanced ECU Coding, Same As MS906 PRO:

Autel MP900TS car scanner diagnostic tool offers same ECU Coding as MS906 PRO/MK908 RPO II, while cut budget at half. It supports Customize OE-Settings (Retrofit/ Modification), Variant Coding/ Offline Programming, Reset Adaptive Data, Match Replaced Components etc. Such as activating/deactivating daytime lights, Flashing br-ake lights during emer-gency bra-king, Displaying real speed via G-PS signal,etc.

1.Program Adaptive Data For New Modules

After component replacement and configuration change, Autel MP900-TS mechanic tool can write adaptive data to the relevant vehicle system and make it re-recognize the new configuration and get optimized vehicle performing, such as replacing steering angle, changing remote start and air conditioning, etc.

2.Retrofit New Modules for Vehicles

For someone who wants to retrofit/modify vehicle modules to upgrade vehicle capacity or optimize car comfortability, you can use Autel MP900-TS obd ii scanner diagnostic tool to meet these needs including modifying headlamps/ fog lights/ brake pad, retrofitting TPMS module/ ADAS system/ lane departure module, installing interior lights/ courtesy lights, etc.

3.Refresh The High-end Functions (Personalization)

More personalized functions include auto parking function, rear-view mirror tilting, one-button lifting windows, digital speed display, adjusting turn signal flashing times, power-on rule statement canceling, residual temperature control, automatic window closing function, US-style daytime running light activation, running light brightness changing, displaying of the real speed via GPS signal, single door opening function, light coding, dashboard coding, etc.

4.Online Coding for More Car Models

Compatible with Nissan, Infiniti, NissanGT-R, Renault, Hyundai, Kia, VW, VW_Brazil, BMW, MINI, Peugeot, Citroen, DS_EU, Porsche, etc.

Note: Functions are NOT universal to all cars, please send your car's model and VIN to us to check compatibility before purchase.

Bi-Directional Control/ Active Test:

MP900-TS bi-directional scan tool features 3000+ active tests that can narrow the diagnostic range to quickly pinpoint problems. Without too much repair time, this Autel scanner avoids disassembling unneeded parts from your vehicles but also saves time spent navigating complex issues. Updated bi-directional control even extends to more modules & actuators, such as:

Temperature Sensor Test, Cooling Fan Activation, Acceleration Device Test, Transmission Shift, Solenoid Calibration, Spark Plug Actuator Test, Radiator Shutter Activation, Quantity Control Valve, Throttle Valve Control Unit Test, Grill Air Shutter System Activation, Compression Test, etc.

Note: Available systems & active tests vary by vehicle model. You can message us to check the compatibility.

40+ Special Functions:

Autel MP900-TS car diagnostic scanner offers a cost-effective value for your budget! Then you can get the same 40+ repair functions, such as: Oil Reset, EPB Reset, SAS Calibration, Airbag Reset, BMS Reset, Brake Bleed, TPMS Reset, DP*F Regeneration, IMMO, Clutch, Trans Adaption, WIN DR ROOF, Headlamp, TEC Learn, A/F Setting, Injector Coding, Suspension Calibration, Throttle Adaption, ABS/SRS, Gear Learning, Sunroof Initialization, Seats Calibration, Language Change, Headlight Matching, CHG Tire Size, Cylinder, Turbocharging, Limit, Trans Adaption, VIN, ACC, HV Battery, Transport Mode, A/C, Rain/Light Sensor ... and keep updating for MORE!

OE-Level All System Diagnostics:

Autel professional scanner MP900TS features OE-level full-system diagnostics, which functions the same as the Snap-on scanners but covers more vehicles. This Autel scanner can dive into every corner of the systems, such as TCM, ECM, EPS, PDM, BCM, etc. to do Read/Clear Codes, ECU info., Live Data, Active Tests, & Special Functions. Also, it presents everything about your ride with a specific report.

✅Read/Clear Codes: Reads and interprets error codes and helps repair to turn of the MIL.
✅Live Data & ECU Info: Views live data to learn vehicle status; Reads ECU information including unit type, version numbers, and more specifications.
✅AutoVIN &Scan VIN/License: Automatically reads and saves your vehicle’s VIN number; Gets the VIN from a license plate or barcode scan, bringing 6X scanning speed.
✅Pre & Post Scan: Identifies any potential problems with the vehicle before any repairs are made, preventing unnecessary repairs and reduce the risk of further damage to the vehicle.
✅WIFI Print: Allows to save, share, and print the overall inspection report via the WIFI, helping you easily maintain vehicle health logs or share the information with mechanics.

150+ Worldwire Vehicle Support:

1.DoIP & CAN FD: New protocol transfers greater quantities of diagnostic data and saves both time and costs. And it also communicates more vehicle models.

2.1996-2026 Worldwide Cars: MP900-TS holds 99% of vehicle supports that covers 150+ brands and US top-selling cars such as VW, Seat, Skoda, Peugeot, Citroen, Renault, Ford, Lincoln, Chrysler, Dodge, GM, Cadillac, Buick, GMC, Acura, Lexus, Volvo, etc.

3.No IP Limitation: Allow users to diagnose the cars everywhere without region limitation.

4.FCA & Renault SGW Cars: MP900-TS car diagnostic scanner helps to secure unl~ock gateway (for Fiat, Chrysler, Dodge, Alfa Romeo, Renault) and successfully perform DTC diagnostics, active test, ECU coding, initialization, advanced checks, etc.

Autel MP900TS Scanner: 6X Faster Configuration, Powerful Expanded Functions:

Scanner for Years Usage:

👍Android 11 leads to 20% faster launch Apps and stable support for diagnostics;
Greatly powerful 4-core RK3566 CPU (1.8GHz) enhances the performnace and diagnostics;
👍Experience a clearer and sharper view of data and information with the large 8” (1024*600) Touchscreen;
👍Thanks to its expanded 4G+64G Memory, this mechanic tool boasts lag-f.ree lightning speed, ideal for storing materials;
👍The high-capacity 7700mAh Battery provides extended usage time even for a whole day;
👍With 8 Megapixel Rear Camera, the Autel scanner MP900-TS allows you to easily take photos and capture details.

New for Better Service:

✅VAG Guided Functions: Easily conducts complex functions with step-by-step instructions on VW, Au.di, Seat, Skoda, etc.
✅Battery Test: Works with BT506 battery tester for professional battery health diagnostics.
✅Component Matching: Matches the new ECUs within the vehicle after ECU replacement.
✅Power Balance: Checks the stability of cylinders and the working of components to ensure the balance of cylinder power output. Only for diesel vehicles.
✅Personalization: Opens/closes preset vehicle settings to meet personalized needs.
✅More: Digital Inspection, WiFi Printing, Pre & Post Scan, Report Management, etc.

Specifications:

Operating: System: Android 11
Processor: Quad core Processor(1.8GHz)
Memory: 4GB RAM & 64GB ROM
Display: 8-inch LCD capacitive touchscreen with 1280x800 resolution
Rear Camera: 8 MP
Connectivity: USB Type-C; USB 2.0: Wi-Fi; Bluetooth; Mini SD card (supports up to 64GB)
Audio Input/Output: Input: N/A; Output: buzzer
Power and Battery: 3.7 V/7700mAh lithium-polymer battery
Charges via 5 VDC power supply
Battery Charging Input: 5 V/3 A
Operating Temp: 0 to 50°C (32 to 122°F)
Storage Temp: -10 to 60°C (14 to 140°F)
Protocols: ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850PWM, ISO11898(High-speed, Middle-speed, Low-speed and Single-wire CAN, fault-tolerant CAN) , SAE J2610, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6, DoIP, CANFD

MaxiPRO MP900TS Package List:

1* Main Unit
1* MaxiVCI V150
1* Power Adapter
1* USB Type-C
1* Cable
1* Soft Cloth
1* Quick Reference
1* Guide
1* Packing List (This document)
1* Carrying Case
