Haute42 Magnetic Hitbox Leverless Controller Button Rim Arcade Controller For PC/PS4/PS5/Switch Stickless Arcade Stick Hitbox

C16 Orange Video

Please Note 1:

The C16 panel has now been upgraded to a frosted panel and is no longer a transparent panel .The frosted panel is more stable and has a better touch, effectively preventing slipping and carrying fingerprints

Our store sells C16 aluminum alloy panels. You can check our store or click on this link to purchase:

https://www.aliexpress.com/item/1005012184374834.html

Haute42 Magnetic Hitbox Leverless Controller Button Rim Arcade Controller For PC/PS4/PS5/Switch Stickless Arcade Stick Hitbox

Product Description

Working voltage: 5V
Link method: USB Type-C
Product size: 299.8mm * 199.8mm * 13.5mm
Supported Platforms : pc /ps3/ps4/switch/ Android/Steam
Product Specifications: Keyboard*1 ,Data Cable (3M) *1 Keycap Puller*1, Art Templates*6,Wind Engine Switch*2

HautePad C16  Series

Magnetic Panel Design, Make DlY Easier And More Convenient，Newly Upgraded RGB Rim And Ambient LEDS Includes 6 sheets of DIY panel paper,Realize DIY freedom and graffiti,Show off your creative talent

01 Compatibility

B — Xinput mode (Windows/Steam)
A — SWITCH mode
X — PS3 / Dinput mode (Raspberry Pi / Android)
Y — PS4 mode (Compatible with PS4 games on PS5 console）
RT — KEYBOARD mode

Input Mode

To change the input mode, hold one of the buttons(as shown above) as the controller is plugged in.
Tips：
This product defaults to Xinput mode，Input mode is saved across power cycles.
If there are games that do not compatible the above input modes , you can enter the Web Configurator to modify them for normal use.

PS4 /PS5 Mode

About PS4 /PS5 8 minute disconnection，there are two ways， one is insert a dongle or a officially authorized PS4 wired controller to the EXT.port，We don't have a recommend one，there are too many choices，maybe you can add our discord with other nice players in haute42 group，oficial Website: haute42-cosmox.com

Web Configurator

This product contains a built-in web-based configuration application which can be started up by holding START when plugging your controller into a PC. Then access http://192.168.7.1 in a web browser to begin configuration.

TURBO

Hold TURBO，then press the button which you need to be set for turbo function，then this button will be continuous sending while you press it,to cancel this turbo key，just repeat the privious step.
The turbo key that set will be cleard when power off.
These keys can be set as a Turbo key: A / B / X / Y / LB / RB / LT / RT

04 RGB LED Setting

●BACK + START + X Next Animation
●BACK + START + A Previous Animation
●BACK + START + Y Brightness Up
●BACK + START + B Brightness Down
●BACK + START + RB LED Parameter Up
●BACK + START + RT LED Parameter Down
●BACK + START + LB Pressed Parameter Up
●BACK + START + LT Pressed Parameter Down
