Android TV Stick H96 Max H313 Allwinner Quad Core 4K Wifi6 BT Voice Assistant Remote Control Media Player Smart TV Box

Android TV Stick H96 Max H313 Allwinner Quad Core 4K Wifi6 BT Voice Assistant Remote Control Media Player Smart TV Box

Notice 1: it does not include adapter,must use 5V/2A adapter to power it, some tv's USB port only has 5V/0.5A,the power is not enough,it will not turn on as normal,must use a 5V/2A adapter to power it.

Notice2: remote controls together for about 10 seconds untill the red light flashing first time,then you can lose your hand.do not hold it too long,or it can not pair well even it shows

"success"

If the remote can not work,

or it shows "success" but not work,

solution:

use a computer mouse to work with it,clink right button exit the remote pairing interface and enter the UI,clink settings -- device perference -- reset. factory reset.

it will restart itself after factory reset, then you can pair the remote again.

-OS Android TV

-CPU Allwinner H313 Quad Core ARM Cortex A53

-GPU Mali-G31 OPenGL ES3.2

-2GB/8GB, 2GB/16GB

-WiFi 2.4G/5G

- Power Supply DC 5V/2A

BT5.0(Only support connecting BT remote control, do not support connecting other BT devices)

-Support

·Video Decoder

Supports video decoding up to 4K@60fps

Supports multi-formats:

H.265 [email protected] up to 4K@60fps

VP9 Profile 2 up to 4K@30fps

AVS2 JiZhun 10bit Profile up to 4K@30fps

H.264 BP/MP/[email protected] up to 4K@30fps

H.263 BP up to 1080p@60fps

·Video Encoder

H.264 BP/MP/HP

H.264 supports l/P frame, and only supports single reference frame

MJPEG/JPEG baseline

Maximum 16-megapixel(4096 x4096) resolution for H.264 encoding

H.264 encoding capability: 1080p@60fps

·JPEG decoder

Supports IPEG encoding with the performance of 1080p@60fps

Supports configurable picture resolutions

Supports configurable quantization tables for the Y component, Cb

component and Cr component respectivelv

Supports OSD front-end overlapping

Supports the color-to-gray function

·HD

Compatible with HDCP 2.2 and HDCP 1.4

Supports DDc and SCDc

Integrated CEC hardware engine

Video support:

2D Video:4K/1080P/10801/720P/576P/480P/5761/480l, up to 4K@60fps

3D Video: 4K/1080P/720P/576P/480P,up to 4K@30fps

Supports RGB/YUV444/YUV422/YUV420 output

Color depth: 8/10-bit

HDR10: compliant with CTA-861.3 and SMPTE ST 2048

Packing list

- 1 x H96 MAX H313 TV Stick

- 1 x Remote Control（Battery not included）

- 1 x Power Cable

- 1 x HD Cable

- 1 x User Manual

- 1 x Retail box
