1/2/3/5/10PCS Universal 433.92 MHZ Wireless Switch Learning Code EV1527 Gate Garage Door Control Remote Control Key

Description

Product parameters:

Product name: 2-button remote control

Product model: 1A09

Modulation method: ASK

Working frequency: 433.92Mhz

Code: Learning code

Working voltage: DC 6V

Battery type: 2016 button battery

Product size: 61 * 28.6 * 12.3mm

Button type: AB style/ON OFF style/Lock style

Special Note:

It is only compatible with 1527 (EV1527, HS1527, HX1527) learning code receivers.
It is not compatible with rolling codes and cloned code.

Operation method:

1. Clear code: Press and hold both buttons simultaneously until the indicator light flashes 3 times, then release one of the buttons and quickly press it 3 times, while keeping one button pressed and not releasing. The indicator light enters a fast flashing state, indicating successful code clearing.

2. Copy Code: When the original remote control and copy remote control are close and the button that needs to be copied is pressed simultaneously, the indicator light will flash slowly for 2 times and then quickly for 3 times to enter a constant light state, indicating successful copying.
