Autel MaxiTPMS TBE200E Tire Diagnostic Scanner Car Tool Laser Tire Tread Depth & Brake Disc Wear 2in1 Tester Perform with ITS600

TBE200E EU F​or European buyer:

The TBE200E EU does not support these three functions：Brake Disc Check，Quick Check，Brake Disc Wear Limit, Please noted it.

MaxiTPMS TBE200E

The MaxiTPMS TBE200E is a laser-enabled tire tread depth & brake disc wear examiner that provides users with quick and accurate wear measurements.
Measure brake disc wear without having to remove tires. It features a 1.65" AMOLED super retina touchscreen, displaying measurement data curves in real-time.
TBE200E provides uneven wear analysis and detailed replacement & maintenance suggestions for quick tire service.
The TBE200E dual cameras enable users to document tire wear and damage and scan Tire Identification Number (TIN). Use the tool separately, or with ITS600 to view and print detailed TPMS reports.

Laser Measurement

• Tire tread depth & brake disc wear check in one tool, no need to remove the wheel during measurement
• Laser measurement with 0.1mm accuracy
• Full tread measurement
• Quick Check both tread depth & brake disc

Real-Time Tire Health Analysis

• Real-time measurement data on touchscreen
• Measurement data curve display
• Uneven wear analysis
• Test detail for single tire tread / brake disc
• Detailed replacement & maintenance suggestions (tire/brake disc replacement, tire rotation/alignment servicing)
• Scan DOT, tire expiration notice, tire recall lookup
• Take photos of tire wear & damage

Comprehensive Test Report

TPMS health, Tire tread depth & brake disc wear characteristics & Repair tips (Requires ITS600)

Features

Specification

Recommended Use:Indoor
Processor:4x ARM Cortex-A35 (1.5 GHz)
Memory:1GB RAM LPDDR3 & 4GB ROM
Display:1.65-inch AMOLED capacitive touchscreen with 348×442 resolution
Connectivity:• Wi-Fi • USB 2.0, Type C
Camera:CMOS WXGA, 1 megapixel & 8 megapixel, 30fps
Audio output Output: Beep
Power and Battery:• 3.7 V/3000 mAh 18650 lithium-ion battery • Charges via 5 V AC/DC power supply
Tested Battery Life:Around 8 hours of continuous use
Battery Charging Input:5 V/1.5 A
Power Consumption:300 mA (AMOLED on with default brightness) @3.7 V
Operating Temp.:-10 to 45°C(14 to 113°F)
Storage Temp.:-20 to 60°C (-4 to 140°F)
Dimensions (W x H x D):283.0 mm (11.14'') x 39.0 mm (1.54'') x 33.5 mm (1.32'')
Net Weight:188 g (0.41 lb.)

Packing List

1 x TBE200E
1 x Calibration Table
1 x Power Adapter
1 x Type C USB Cable
1 x Quick Reference Guide
1 x Packing List
1 x Carrying Case
1 x Screen Wiper
