1PCS TMP117 SEN-15805 High Precision Temperature Sensor

Product Description:

DRV8838 Brushed DC Motor Driver Module, Low Voltage Single-Channel Carrier Board for Robotics, Toys, and DIY Projects

DRV8838 is a tiny H-bridge motor driver IC that can be used for bidirectional control of one brushed DC motor at 0 V to 11 V. It can supply up to about 1.7 A continuously and can tolerate peak currents up to 1.8 A for short durations, making it an ideal driver for small motors that run on low voltages. The DRV8838 is a great IC, but its small, leadless package makes it difficult for the typical student or hobbyist to use; our breakout board gives this driver the form factor of a 10-pin DIP package, which makes it easy to use with standard

 and 0.1″

. Since this board is a carrier for the DRV8838, we recommend careful reading of the

. The board ships populated with SMD components, including the DRV8838, and adds a FET for reverse battery protection.

Alternative driver options

This motor driver is essentially a smaller, lower-cost, single-channel alternative to our

 and

, which have very similar operating voltage ranges and current ratings but offer an additional motor channel.

For higher-voltage alternatives to this driver, please consider our

,

, and

.

Features

H-bridge motor driver: can drive one DC motor

Motor supply voltage: 0 V to 11 V

Logic supply voltage: 1.8 V to 7 V

Output current: up to 1.7 A continuous (1.8 A peak); operation at low motor and logic supply voltages reduces the maximum continuous output current

PHASE/ENABLE interface (one pin controls direction and another controls speed)

Inputs are 3V- and 5V-compatible

Under-voltage lockout on the logic supply and protection against over-current and over-temperature

Reverse-voltage protection on the motor supply

Compact size (0.5″×0.4″) with the form factor of a 10-pin DIP package

About us:

We deal in all kinds of lC brands world-wide.

Our products are widely applied in civilian, industrial and military fieldslE work, communication, home appliances, RF, video display, memoriesRAM development, medical instruments, power supply system, programcontrolleddevices,digital devices,industrial equipments, aviation andnavigation equipments, etc.

We also supply Amplifier board,LCD Display,Soldering iron ,Temperature controller ,mppt solar controller,charger,Active balancer,BMS,battery tester,indicator ,esp8266 and so on

We have extensive industry knowledge and sufficient inventory. This enables us to provide a complete and versatile technical supports to our customers. Our products have been exported to many countries and regions around the world, and we have a good reputation among our customers. We welcome customers, chambers of commerce, and friends from all over the world to contact us and seek mutually beneficial cooperation.

Packaging & Shipping:


Payment Details:
1.Alibaba Trade Assurance Order(Credit Card);
2.T/T Bank Transfer;
3.Paypal;
4.Western Union;
5. Contact us if u don't find your payment method.

Shipment Details:
1.After payment and confirmation, we will prepare goods efficiently and deliver them within 1-3working days.
2.You are free to choose DHL,UPS,Fedex,ARAMEX,EMS,Economic Airmail..as your favor shipping way, If you have any special requirement,please freely indicate in the remarks.
3. If there is any accident or delay of the package,the shipping service provider will assume the responsibility on our behalf.
