BSIDE Graphic Digital Multimeter Oscilloscope OS1 High-precision Multitester Resistance Voltage Capacitance Hz Continuity Tester

Product Advantages:

[Multimeter Mode]: BSIDE OS1 multimeter measures MAX/MIN/AVG, capacitance, diode, voltage, resistance, continuity, etc.

[Oscilloscope Mode]: Handheld oscilloscope features 10MHz bandwidth, 48MSa/s sampling rate, 64kb record depth, auto/normal/single trigger function, etc.

[3.2" Full-Viewing LCD]: Digital multimeter has a full-viewing 3.2 inch full-viewing screen, which greatly enhance your reading experience.

[BNC-Ports Free]: Oscilloscope multimeter with no BNC port design, whatever measurement requires only use the same test leads, which is convenient for your work.

[Rechargeable]: Scope tester comes with 1200mAh rechargeable battery, ensuring that you never have to worry about running out of power during measurements.

[Protective Case]: Oscilloscope multimeter with durable protective case for protection against shocks, friction and bumps.

[Carrying Case]: Portable oscilloscope comes with a high quality carrying case, perfect for use while you're on the go.

Features:

Handheld oscilloscope
Portable graph multimeterr
Rechargeable color display oscilloscope
Tested data can be saved and exported to your computer
Full-viewing oscilloscope with low battery indication

Specifications:

MAX Display: 6000 counts
Screen Size: 3.2 inch
Bandwidth: 10MHz
Real-time sample rate: 48MSa/s
Input Impedance: 1MΩ
Maximum Input Voltage: 300V (DC+AC peak)
Horizontal SEC Range: 50ns/div -20s/div
Vertical Sensitivity: 200mV/div -100V/div
DC Voltage:
60mV 0.01mV ±(1%+5);
600mV/6V/60V 0.1mV/0.001V/0.01V/ ±(0.8%+3); 600V/1000V 0.1V/0.1V ±(1%+5)
AC Voltage:
60mV 0.01mV ±(1.2%+5);
600mV/6V/60V 0.1mV/0.001V/0.01V/ ±(1%+3); 600V 0.1V ±(1.2%+5); 750V 1V ±(1.2%+5)
Resistance:
600Ω 0.1Ω ±(1.2%+5); 6kΩ/60KΩ/600KΩ 0.001KΩ/0.01KΩ/0.1KΩ ±(1.0%+3);
6MΩ 0.001MΩ ±(1.2%+5); 60MΩ 0.01MΩ ±(1.5%+5)
Capacitance:
999.9nF 0.1nF ±(5%+20);
9.99µF/999.9µF 0.001µF/0.01µF ±(4.5%+5); 99.99mF 0.001mF ±(5.0%+10)
Diode: Yes
Continuity: Yes
Power: 1200mA battery (rechargeable)
Size: 143 x 66 x 21 mm
Weight: 160g

Package Includes:

1 x Handheld Oscilloscope Multimeter
1 x Upgrade Test Leads；
1 x Carrying Case
1 x USB Charging Cable
1 x User Manual
1 x 12-month after-sales warranty card；
1 x Color Box.
