PZEM-017 DC Voltage Current Energy Power Meter Ammeter Voltmeter Electric Module Amperemeter Wattmeter Modbus RS485 10A 300A

Peacefair PZEM-017 Single-phase DC Voltage Current Energy Power Meter Ammeter Voltmeter Electric Kwh Wattmeter Modbus RS485 300V 200A Shunt

This document describes the specification of the PZEM-003/017 DC communication module, the module is mainly used for measuring DC voltage, current, active power, frequency and energy consumption, the module is without display function, the data is read through the RS485 interface.

PZEM-017: Measuring Range 50A、100A、200A、300A (the current range is depend on the external shunt specification )

Peacefair Brand Official Store From The Manufacturer

All orders will be shipped with a tracking number, you can easily find the record from the website: www.17track.net/en

Please click this link to download the software and the user manual.

Download address：https://drive.google.com/file/d/1mKYhi6XtTuA2cUlZ6FWZD0DIlMvQBDQT/view?usp=sharing

Account: admin Password: 1

1. Working voltage: 0.05 ~300VDC

2. Test voltage: 0.05 ~300VDC

3. Rated power: 0.02A-300A/0.2-90kW

4. Measurement accuracy: 1.0 grade

Function and Display format

1  Voltage

1.1   Measuring range:0.05-300V. (when the test voltage is ＜7V, please use the independent power supply mode)

1.2   Resolution:0.01V.

1.3   Measurement accuracy:1%.

 2   Current

2.1   Measuring range:0.01-10A(PZEM-003);0.02-300A(PZEM-017;can be matched with 50、100、200、300A four kinds of shunt).

2.2   Resolution:0.01A

2.3   Measurement accuracy:1%

3 Power

3.1   Measuring range:0.2-90kW(PZEM-017)

3.2   Resolution: 0.1W

3.3   Measurement accuracy:1%

4 Energy Consumption

4.1   Measuring range: 0-9999kWh

4.2   Resolution: 1Wh

4.3   Measurement accuracy:1%

Reset energy: use software to reset.

Over Voltage alarm

Voltage threshold can be set, divide into high voltage and low voltage threshold, when the measured voltage exceeds the threshold, it can alarm

The default high voltage threshold is 300V, the default low voltage threshold is 7V.

Communication interface

RS485 interface.

Communication protocol

Physical layer protocol

Physical layer use UART to RS485 communication interface.

Baud rate is 9600, 8 data bits, 2 stop bit, no parity.

Other instructions

1  RS485 interface is passive output, need external connect 5V power supply and the the external power supply should ＞100mA.

2  When the input test voltage is less than 7V, it must supply 5V independent work voltage   through MICRO USB port；

Note: Do not use the USB port bring by your PC to be the independent power supply, otherwise it may damage your PC !

Working temperature

-20’C ~ +60’C

1X PZEM-017module

1X 200A shunt
