8/10 Inch Black Exhaust Fan 7-Blade High-Speed Ventilation Auto Backdraft Damper Low Noise 60-70dB Kitchen Bathroom Workshop

Description

A good exhaust fan will bring you a more comfortable life. It adopts a high-efficiency copper wire motor and 7-blade fan, with strong power and large air volume, which can provide strong wind power and fast ventilation. Premium materials make it stable and long-lasting. We believe it will effectively enhance the air circulation in your room, creating a cleaner, healthier, and more comfortable living or working environment for you.

Application

It is ideal for workshops, basements, garages, warehouses, apartments, kitchens, bathrooms, living rooms, offices, commercial settings, and other places that require constant ventilation.

Specifications（8 Inch EU）

Color: Black

Style: Modern

Material: Cast Iron, Steel and Iron, Aluminum Alloy

Process: Painting

Mount Type: Wall Mounted or Window Mounted

Shape: Rectangular, Round

Power Source: Wired

Assembly Required: No

Motor Type: Copper Wire Motor

Voltage: AC 220V

Frequency: 50Hz

Power: 80W

Motor Speed: 2600r/min

Number of Fan Blades: 7

Noise: About 60-70dB

Screw Hole Spacing: 21cm/8.27in

Outlet Diameter: 19.5cm/7.68in

Product Size: 25*25*15cm/9.84*9.84*5.91in

Package Size: 25.5*25.5*16cm/10*10*6.3in

Gross Weight: 2kg/4.41 lbs

Net Weight: 1.9kg/4.19 lbs

Specifications（8 Inch US）

Color: Black

Style: Modern

Material: Cast Iron, Steel and Iron, Aluminum Alloy

Process: Painting

Mount Type: Wall Mounted or Window Mounted

Shape: Rectangular, Round

Power Source: Wired

Assembly Required: No

Motor Type: Copper Wire Motor

Voltage: AC 110V

Frequency: 60Hz

Power: 80W

Motor Speed: 2600r/min

Number of Fan Blades: 7

Noise: About 60-70dB

Screw Hole Spacing: 21cm/8.27in

Outlet Diameter: 19.5cm/7.68in

Product Size: 25*25*15cm/9.84*9.84*5.91in

Package Size: 25.5*25.5*16cm/10*10*6.3in

Gross Weight: 2kg/4.41 lbs

Net Weight: 1.9kg/4.19 lbs

Specifications（10 Inch EU）

Color: Black

Style: Modern

Material: Cast Iron, Steel and Iron, Aluminum Alloy

Process: Painting

Mount Type: Wall Mounted or Window Mounted

Shape: Rectangular, Round

Power Source: Wired

Assembly Required: No

Motor Type: Copper Wire Motor

Voltage: AC 220V

Frequency: 50Hz

Power: 100W

Motor Speed: 2600r/min

Number of Fan Blades: 7

Noise: About 60-70dB

Screw Hole Spacing: 25.5cm/10in

Outlet Diameter: 25cm/9.84in

Product Size: 30*30*16cm/11.81*11.81*6.3in

Package Size: 30.5*30.5*16.8cm/12*12*6.6in

Gross Weight: 2.5kg/5.51 lbs

Net Weight: 2.38kg/5.25 lbs

Specifications（10 Inch US）

Color: Black

Style: Modern

Material: Cast Iron, Steel and Iron, Aluminum Alloy

Process: Painting

Mount Type: Wall Mounted or Window Mounted

Shape: Rectangular, Round

Power Source: Wired

Assembly Required: No

Motor Type: Copper Wire Motor

Voltage: AC 110V

Frequency: 60Hz

Power: 100W

Motor Speed: 2600r/min

Number of Fan Blades: 7

Noise: About 60-70dB

Screw Hole Spacing: 25.5cm/10in

Outlet Diameter: 25cm/9.84in

Product Size: 30*30*16cm/11.81*11.81*6.3in

Package Size: 30.5*30.5*16.8cm/12*12*6.6in

Gross Weight: 2.5kg/5.51 lbs

Net Weight: 2.38kg/5.25 lbs

Package Included

1* Exhaust Fan

1* English Manual

Key Features

Build to Last: It is made of premium cast iron, steel and iron, and aluminum alloy, and its surface has been treated with painting technology, which is very shockproof, impact-resistant, rust-proof, sturdy, and has a long service life.

Excellent Ventilation Effect: High power copper wire motor, 2600r/min high speed, and seven fan blades can provide strong power and blow strong wind, helping you to quickly ventilate the kitchen, bathroom, etc., and improve efficiency.

Thoughtful Design: It adopts an automatic backdraft damper design, which can open and close the air door with the wind when in use to exhaust indoor fumes, polluted air, and odors. When it is closed, it can block flying insects, mice, etc. from entering the room, creating a clean and comfortable living environment for you.

Low Noise: It uses a low-noise motor (about 60-70dB), which does not produce a lot of noise to disturb others when in use.

Space Saving: The compact size(9.84*9.84*5.91in) allows you to install the product without taking up much space.

Ready to Use: This product does not require assembly and can be used directly upon receipt, which is very time-saving and convenient.

Easy to Clean: Thanks to its smooth surface, simple structure and removable design, you can easily clean it with water and a rag (not included).

Ideal Gift: With its beautiful appearance and practical performance, it is the ideal surprise for those who need to ventilate their warehouses, kitchens, or bathrooms.

Buy with Confidence: We stand behind all our guests and look forward to assisting you with your purchase. It is our pleasure to answer your confusion and questions. The end of the story between us is not "we sell and you buy".

Details

Pre-drilled Holes: They allow you to easily secure the product to a wall or window.

Protective Mesh: It not only prevents accidental entry of hands into the machine but also prevents debris from being sucked into the machine and causing damage.

Rounded Corners and Edges: The corners are rounded and smooth to reduce abrasions from collisions and improve safety.

Notes

1. Please carefully check if the size is suitable before placing an order.

2. Please note that this product is not recommended for installation on the ceiling as it may affect the product's service life.

3. Please note that when installing the smoke pipe, the backdraft damper needs to be removed.

4. Please read the operating manual completely before use. And pay particular attention to the safety instructions included.

5. Please allow the slight color difference caused by the shooting light and 1-3cm error due to manual measurement, and make sure you do not mind before you order.
