10pcs 3W 5W 7W 10W High Power LED Source Chip 13mm 20mm 24mm SMD LED COB Light Bulb LED Diode Light Lamp Spotlight Downlight DIY
4.16$
2.46$
Quantity:
1
Availability:
Emitting Color
Wattage
Card Payments
Crypto Payments
Easy return
Reliable Shipping
Size：2011
Power: 3W/5W/7W/10W
Color: 3000k Warm White/4000k Natural white/6500k Cold White
Current: 250mA
Voltage: 3W:DC9-10V/5W:DC15-17V/7W:DC20-22V/10W:DC30-32V;
Ra:≥70
Lumen: 90-100LM/W
Luminous crystal size: 10 * 21mil
Chip size: 20 * 20mm
Luminous surface diameter: 11 * 11mm
Series parallel connection: 3W:2B3C/5W:2B5C/7W:2B7C/10W:2B10C;
Number of crystals：3W:6pcs/5W:10pcs/7W:14pcs/10W:20pcs;
Service life: 5000h
Metal material: aluminum
Working conditions: must have a radiator
Temperature condition: Can't be greater than 60 degrees
Required driver: LED constant current drive power
Size：1311
Power: 3W/5W/7W/10W
Color: 3000k Warm White/4000k Natural white/6500k Cold White
Current: 250mA
Voltage: 3W:DC9-10V/5W:DC15-17V/7W:DC20-22V/10W:DC30-32V;
Ra:≥70
Lumen: 90-100LM/W
Luminous crystal size: 10 * 21mil
Chip size: 13*13mm
Luminous surface diameter: 11 * 11mm
Series parallel connection: 3W:2B3C/5W:2B5C/7W:2B7C/10W:2B10C;
Number of crystals：3W:6pcs/5W:10pcs/7W:14pcs/10W:20pcs;
Service life: 5000h
Metal material: aluminum
Working conditions: must have a radiator
Temperature condition: Can't be greater than 60 degrees
Required driver: LED constant current drive power
Size：2422
Power: 3W/5W/7W/10W
Color: 3000k Warm White/4000k Natural white/6500k Cold White
Current: 250mA
Voltage: 3W:DC9-10V/5W:DC15-17V/7W:DC20-22V/10W:DC30-32V;
Ra:≥70
Lumen: 90-100LM/W
Luminous crystal size: 10 * 21mil
Chip size: 24 * 22mm
Luminous surface diameter: 20*20mm
Series parallel connection: 3W:2B3C/5W:2B5C/7W:2B7C/10W:2B10C;
Number of crystals：3W:6pcs/5W:10pcs/7W:14pcs/10W:20pcs;
Service life: 5000h
Metal material: aluminum
Working conditions: must have a radiator
Temperature condition: Can't be greater than 60 degrees
Required driver: LED constant current drive power
