RS550 DC Motor 10.8V/12V/16.8V/18V/21V Micro Electric Screwdriver Motors with 9/11/12/13/14/15 Teeth High Torque Gear Box Motor

Description

RS550 DC Motors 10.8V/12V/14.4V/16.8V/18V/21V/25V Drill Motor with 9/11/12/13/14/15 Teeth High Torque Gear Box Electric Motor Screwdriver

Features:

- RS550 with 0 gear, 9-15 gear teeth DC motor, are specially designed for replacement rechargeable lithium battery cordless electric drill / screwdriver.

- Stainless steel shell material, Pure copper coil, low current, high efficiency, strong output power.

- Low noise, high speed and high torque, good heat dissipation, stable performance and long life.

- Easy to use, the front can be fixed with 2 M3 screws.

- Widely used in cordless drill, table drill, electric drill and electric screwdriver etc.

Detailed Description:

Motor Model: RS550

Material: Metal

Number of gears: 9 teeth, 11 teeth, 12 teeth, 13 teeth, 14 teeth, 15 teeth

Voltage: 10.8V / 12V / 14.4V / 16.8V / 18V / 21V / 25V

No load Speed: 21500-29000RPM

Rated Power: 80W

Size:

Motor length: 75.1mm

Motor diameter: 37.2mm

Motor shaft length: 12mm

Motor shaft diameter: 3.2mm

Motor gear diameter: 7.9mm (9 Teeth), 8.8mm(11 Teeth),8.6mm(12Teeth),9.2mm(13 Teeth), 8.2mm(14 Teeth)9.5mm(14 Teeth),10.4mm(15 Teeth)

Motor gear thickness: 6.5mm (9 Teeth), 5.2mm (11 Teeth),5.2mm(12Teeth), 3.8mm (13 Teeth), 6.8(14 Teeth),5.8mm(14 Teeth),8.0mm(15 Teeth)

Motor installation hole distance: 25mm

How to choose a motor for a rechargeable electric drill / screwdriver:

1. Confirm your motor model is RS550 or motor diameter(about 37.2mm), and motor body length(about 57mm), and total length(about 75.1mm).


2. Confirm the voltage of your motor (DC10.8V-25V) and choose a motor with the same or similar voltage.


3. Confirm the number of teeth of your motor (0teeth, 9-15 teeth), make sure to choose the motor with the same number of teeth, and verify that the outer diameter and thickness of the gears are the same or similar.

Part of applicable lithium electric drill models:

10.8V: GSR 10.8-2-LI, GSB 10.8-2-LI, GSR 108-2-LI, GSB 108-2-LI

12V: GSR 12-2-LI, GSB 12-2-LI, GSR 120-LI, GSB 120-LI

14.4V: GSR 14.4-2-LI, GSB 14.4-2-LI, GSR 144-2-LI, GSB 144-2-LI

18V: GSR 18-2-LI, GSB 18-2-LI, GSR 180-2-LI, GSB 180-2-LI

GSR 10.8 V LI-2 - 3 601 H68 100, GSR 12-LI - 3 601 J92 901

GSR 12-2-LI - 3 601 H68 101, PS21 - 3 601 J92 910

GSR 12V-15 - 3 601 H68 102, PS21 - 3 601 J92 911

PS31 - 3 601 H68 110, GSR 10.8 V LI - 3 601 J92 9E0

PS31 - 3 601 H68 111, GSR 10.8 V LI - 3 601 J92 9F0

GSR 10.8-2-LI - 3 601 H68 150, GSR 10.8 V LI - 3 601 J92 9G0

GSR 10.8-2-LI - 3 601 H68 180, GSR 10.8 V LI - 3 601 J92 9H0

GSR 12-2-LI - 3 601 H68 181, GSR 12V-15FC - 3 601 JF6 000

GSR 10.8-2-LI - 3 601 H68 1B0, GSR 12V-140FC - 3 601 JF6 010

GSR 10.8-2-LI - 3 601 H68 1C0, GSR 10.8-15 FC - 3 601 JF6 050

GSR 10.8-2-LI - 3 601 H68 1E0, GSR 12V-15FC - 3 601 JF6 080

GSR 10.8-2-LI - 3 601 H68 1G0, GSR 10.8-15 FC - 3 601 JF6 0B0

GSR 10.8-2-LI - 3 601 H68 1E0, GSR 12V-15FC - 3 601 JF6 080

GSR 10.8-2-LI - 3 601 H68 1G0, GSR 10.8-15 FC - 3 601 JF6 0B0

GSR 10.8-2-LI - 3 601 H68 1H0, GSR 12V-15FC - 3 601 JF6 0E0

GSR 12-2-LI - 3 601 H68 1L0, GSR 12V-15FC - 3 601 JF6 0K0

N​ote

If it is found that the motor has moved down and the cooling fan is stuck like in the picture due to transportation, and the magnetic tile inside is not broken, a screwdriver can be used to push it up from the fan mouth to the appropriate position, and the motor can operate normally.

Package include

Package included:

1x RS550 Electric Motor
