Carburetor Engine 2 Barrel 40 IDF For VW Bug For Volkswagen Beetle For Porsche

Introduction:

A carburetor is a device to mix air and fuel for internal combustion engines in the proper ratio for combustion. The fuel and air mixture is too rich if it has an excess of fuel, while too lean if there is not enough. Therefore, our high quality carburetor is the perfect solution for the appropriate ratio of air and fuel mixture and finally provides a good engine performance

Application:

Carburetor for modification with Any application that utilizes the IDF carburetor.

replacement fit For VW Beetle Bug /for Fiat / for Porsche  with Air Horn

Specifications:

For Dual Application, 2 Barrel Carb Carburetor

Main Bolts: 115

Emulsion Tubes: F11, F-11

Air Corrector Bolts: 200

Idle Bolts: 52

Needle & For Seat: 200

Accelerator Pump ForBolts: .50

Pump Exhaust For Bolts: 550

Venturis:28mm

Aux Venturis: 4.50mm

Needle Valve: 1.75mm

Bolt Hole Spacing Length&Width :134.5(max)mm×64(max)mm( center to center )

Throttle Bore Throat Size Measures: 40mm

Choke Air Horn Inner  Diameter: 46mm

Choke Air Horn Outer Diameter: 65mm

Manufacturer Part Number: for 40 IDF

Material: Heavy Duty  Zinc Alloy Construction

Placement On Vehicle: Front

Weight: 2.2 kg

Package Size:23*21*15 cm

Note:

*Please allow 1-2mm error due to manual measurement.

* Please check the measurement information of the carburetor to ensure you are ordering the correct part.

Package Included:
1x Carburetor
​



Feature:
1.Get better driving experience and handling with high performance  carburetor that will keep you in control on road
​2.Brand new and high quality carburetor replacement part. Helpful for avoiding waste of oil to some extent.
​3.Low fuel consumption, Start fast stable idle speed, Heavy Duty Metal Construction
​4.Nickel plating surface to keep the carb last much longer
​5.100% tested For reliability and performance,simple installation .
​

Notice:
*The oil channels of carburetors will be blocked without cleaning.Please clean up the oil channels and air filters as well as use the clean fuel before installing the carburetors.
​*Professional installation recommended/We recommend that this be installed by a qualified mechanic with experience doing this type of work.  (No Instruction Included)
​* To ensure correct purchase,please compare carburetor against picture before you purchase.
