1PC IS917 PCBA for NAND Flash USB3.0 U Disk Weldable TSOP48 BGA132 BGA136 BGA152 Chips USB 3.0 U Disk PCB Main Controller DIY

1PC IS917 PCBA for NAND Flash USB3.0 U Disk Weldable TSOP48 BGA132 BGA136 BGA152 Chips USB 3.0 U Disk PCB Main Controller DIY

Main Controller IC : IS917

USB type: USB3.0

PCB size:14*33mm(without the USB port size)

Support IC: BGA152/132/136 TOP48 (two solder chips,every chips need 2CE.But if you weld one chip in PCB,MAX 4CE).

Usage:（USB3.0 interface High speed）, DIY Recycle SSD Flash Chips.

NAND flash R/W Strick

Can be delete all partition

Can be Read & Write

Check whether the chip supports the website: www.flashinfo.top (please note that the results found are for reference only, not 100% sure that it can be supported, there are many factors that affect the failure of DIY, more thinking, more experiments, more communication).

About jumpers:

- The board defaults to 3D jumpers, please jumper according to the following method (for reference only, please point out if there is an error).

- 2D particles: first remove R6, R7, R11, if it is Toshiba and SanDisk, short R10 and R12, if it is Micron, short R10 and remove R12 from Intel.

- 3D particles: Support Micron Intel, short R11 R12 R6 R7, remove R10.

It can weld TSOP48, BGA132, BGA136, BGA152 flash memory chips, and supports up to 4CE. The is917 is a single-channel master control. Theoretically, the speed can reach up to 150MB/s for reading and 100MB/s for writing. The actual speed depends on the chip used.
